The Ultralight Articulating Night Vision Binocular
Our kick starter product and first in a series of articulating binocular devices. This is the lightest 18mm binocular on the market to date at a functional weight of 14.55 oz in the lightest configuration (I.e. Lightweight optics, Diopter assemblies, and hardware) or 18.42 oz. fully assembled with MIL-Standard optics, assembles, and battery. The articulating design allows users to use one eye or both eyes enabling the simultaneous use of a thermal optic or other non-passive aiming systems. This also enables users to operate vehicles without limiting head space by eliminating the need to stow the unit upright or to tuck the pods against the helmet when stowed.
It is simple with a minimalist design. An onboard battery with no remote power keeps things simple and wires off the helmet. Push button on/off in the cap to reduce weight and reduce the footprint of the bridge. Individual pod power on/off when articulated to the side for single or dual eye use and to eliminate backsplash when stowed or rotated out.
An original new “Friction Lock Interpupillary Adjustment” feature allows users to quickly and easily set IP stop distance with a simple rotate into place and forget design. No tools or knobs.
This unit is light weight without compromising strength. It is rugged and exceeds MIL-STD-810G plus has been drop tested to the NATO 1.5 meter firearms drop test standard. All our products are designed and hand built in New Hampshire, USA.
Specifications
Material(s)
Impact resistant polymer & 6061-T6 aerospace grade
aluminum, aerospace Grade 4 Titanium
____________________
Finish
H-Series Cerakote
(Matte Black, Coyote, and OD)
____________________
Tube Type
18mm MX-10160 style or MX11769 style with EGAC pigtail
removed.
____________________
IR Iluminator
No
____________________
Individual Pod on/off
Yes, individually.
____________________
Housing Weight
4.33 oz./0.27 lbs / 123g
____________________
Device Weight Standard
17.81oz./1.13 lbs/505 g
(Mil-Spec PVS-14 lenses and Photonis Image Intensifiers)
____________________
Device Weight Lightweight
14.55 oz. / 0.90 lbs / 412.6 g (RPO 3.0 PVS-14 lenses and Photonis Image Intensifiers)
____________________
On-Board Power
CR123A onboard with a runtime of ~25hours
____________________
Out-Board Power
Optional LEMO port
____________________
Manual Gain Control
No
____________________
Ingress rating
Exceeds IP-68, and MIL-STD-810H
____________________
Warranty
Lifetime repair or replacement of all housing components no
questions asked.(Does not cover damages to intensifier tubes.
or lens assemblies)
IPD Stops
Tool-less quick adjustment Inner pupillary distance stops. Allows the user to set a stopping distance for his or her unique pupillary distance but can be pushed past stopping point in either direction for infinite quick adjustments
Independent Articulation on/off
Left and right pods function independently when articulated up for an individual on/off feature
Tactile on/off battery cap
A simple bare bones, on/off battery cap. Ergonomically designed with the tactile on/off click much like your favorite flashlight
LEMO Port Baseplate
Optional LEMO port baseplate for extended use with external power pack or onboard CR123A
Aluminum Dovetail
Dovetail and major structural components made out of high grade aluminum for extreme durability and unique design
